Pelvic Ultrasound Imaging
A pelvic ultrasound is the single most effective way of evaluating a pelvic mass with transvaginal ultrasonography being preferable due to its increased sensitivity over transabdominal ultrasound.
Where imaging is not undertaken in gynaecology setting, and the sonographer is not performing TVUS at the time of initial scan, they must ensure a TVUS is arranged and performed ideally within 6 -12 weeks depending on TAUS finding.
Use of IOTA Group rules to classify benign and malignant lesions on ultrasound
When describing ovarian masses on ultrasound, it is suggested that using the International Ovarian Tumour Analysis (IOTA) Group rules can indicate the likelihood of a lesions being benign or malignant. They are estimated to have a sensitivity of 95% and specificity of 91%, with a positive likelihood ratio of 10.37 and negative likelihood ratio of 0.06 [2]. The features for IOTA rules are outlined in the table below.
|
B-rules
|
M-rules
|
|
Unilocular cysts
|
Irregular solid tumour
|
|
Presence of solid component with largest being <7 mm
|
Ascites
|
|
Presence of acoustic shadowing
|
Papillary structures: at least four
|
|
Smooth multilocular tumour with largest diameter <100 mm
|
Irregular multilocular solid tumour with largest diameter >100 mm
|
|
Blood flow absent on Doppler
|
Very strong blood flow present
|
Table 1: IOTA B and M rules
MRI and CT imaging
Routine use of CT or MRI is not indicated. However, this may be appropriate in some cases to aid diagnosis and ongoing management as outlined in West of Scotland Cancer Network, Guidelines for imaging of Gynaecological Malignancy.
Blood tests
CA125
CA125 may be elevated in many physiological and pathological conditions, with gynaecological and non-gynaecological causes. Elevated CA125: investigation & management, Gynaecology (1113)
The widely accepted normal range of CA125 in GG&C is 0-35iu/ml.
In the pre-menopausal woman, the RCOG advises that a CA125 level is not routinely needed in the assessment of simple cysts.
However, where it is measured and raised in the context of a cyst, RCOG guideline suggest [1]
- Raised and less than 200 units/ml, further investigation may be appropriate to exclude/treat the common differential diagnoses
- When serum CA-125 levels are raised, repeat CA125 after 2 months should be performed as rapidly rising levels are more likely to be associated with malignancy than high levels which remain static. Elevated CA125: investigation & management, Gynaecology (1113)
- Where the CA 125 is significantly elevated >200 units/ml, further imaging should be organised e.g. urgent CT Chest, abdomen and pelvis. Referral to gynaecological oncology MDT should be considered once further imaging is complete.
The Risk of Malignancy Index (RMI I)
The use of RMI I scoring has been shown to be an effective method of determining women who are at low or high risk of malignancy. This will determine the need for onward referral and management required.
Use of the original RMI I calculation remains the most utilised, widely available and validated effective scoring system, with modifications using RMI II, RMI III and RMI IV systems showing no clinical benefit [2].
RMI I scoring includes measurement of CA125 and the assessment of specific ultrasound features. Therefore, ultrasound reporting must detail the morphological features present to enable calculation of the RMI I accurately.
Calculation of RMI I
The method for calculation of RMI is outlined below. The parameters used are Ultrasound score (U), Menopausal status (M) and CA125 (iu/ml).
- The ultrasound result is scored 1 point for each of the following characteristics: multilocular cysts, solid areas, metastases, ascites and bilateral lesions. U = 0 (for an ultrasound score of 0), U = 1 (for an ultrasound score of 1), U = 3 (for an ultrasound score of 2–5).
- The menopausal status is scored as 1 = premenopausal and 3 = postmenopausal. This guideline is directed at premenopausal women and therefore all will be allocated the same score of 1 for menopausal status.
- Serum CA125 is measured in iu/ml
Interpretation of RMI I score
An RMI I of <200 is used as a cut off for malignancy risk.
If the RMI is >200, a USOC referral must be made to gynaecology and the case should then be referred to the Gynaecology/Oncology MDT via Teams for decision regarding diagnosis and further management.
A CT scan of chest, abdomen and pelvis (with contrast where appropriate) should be arranged in the interim as per West of Scotland Cancer Network, Guidelines for imaging of Gynaecological Malignancy . Currently, this can only be requested in secondary care and should be considered at point of vetting. If ordered at point of vetting, the results should be reviewed by the clinician who then assumes care after clinic appointment.
If the RMI is <200, but the woman is symptomatic or CA125 >35, then surgical management should be considered. Surgery should also be considered if the RMI is < 200 but the cyst >5cm in diameter.
Other blood tests
In addition to CA125, LDH, αFP and hCG should be measured in all women under the age of 40 with a non simple ovarian mass, as raised levels are associated with germ cell tumours.
